• Moxa ioLogik E1512-M12-T rugged I/O module with ports and interface
1 1

Moxa

Moxa ioLogik E1512-M12-T | ioLogik E1500 Ethernet Remote I/O, 4DI 4DIO, M12, -40 to 85°C

Moxa ioLogik E1512-M12-T | ioLogik E1500 Ethernet Remote I/O, 4DI 4DIO, M12, -40 to 85°C

Authorised Moxa Partner

ioLogik E1512-M12-T

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Moxa ioLogik E1512-M12-T is a rugged Ethernet remote I/O unit with 4 digital inputs and 4 software-configurable DIO channels, an M12 D-coded Ethernet port and an extended -40 to 85°C operating range. Built for railway and rolling-stock applications, it uses an aluminium housing and a threaded M12 connector with spring-type terminal blocks for vibration-resistant cabling.

The unit supports Modbus TCP Server (Slave) and Moxa AOPC active tag communication, with the MXIO library available for Windows and Linux. It is configured via a web browser or the ioSearch utility for mass deployment, runs from 12 to 48 VDC, mounts on DIN-rail or wall, and is compliant with EN 50121-3-2, EN 50121-4 and a portion of EN 50155.

Features

- User-definable Modbus TCP Slave addressing
- Active communication with MX-AOPC UA Server
- Easy mass deployment and configuration with the ioSearch utility
- Web browser configuration
- MXIO library for Windows or Linux
- Wide operating temperature range of -40 to 85°C
- Channel-to-channel isolation on DI channels
- Ruggedised aluminium housing
- Threaded M12 Ethernet port and spring-type terminal block for vibration-resistant cabling
- Compliant with EN 50121-3-2, EN 50121-4 and a portion of EN 50155

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 4 x digital input channels
- 4 x DIO channels, software configurable as DI or DO
- 1 x 10/100BaseT(X) M12 D-coded 4-pin female Ethernet port
- Digital inputs: dry contact and wet contact (NPN or PNP), 250 Hz counter frequency, 2 channels per COM
- Digital outputs: sink type, 200 mA per channel, 0.65 A per channel over-current protection at 25°C
- Isolation: 3k VDC or 2k Vrms
- Magnetic isolation protection: 1.5 kV (built-in)
- Connectors: spring-type Euroblock terminals
- Protocols: Modbus TCP Server (Slave), Moxa AOPC (Active Tag), MXIO library
- Input power: 12 to 48 VDC
- Operating temperature: -40 to 85°C (-40 to 185°F)
- Housing: aluminium, DIN-rail and wall mounting
- Compliance: EN 50121-3-2, EN 50121-4 and a portion of EN 50155

FAQs

Q: What I/O channels does the ioLogik E1512-M12-T provide?
A: It provides 4 digital input channels and 4 DIO channels that can be configured by software as digital inputs or digital outputs.

Q: What type of Ethernet connector does it use?
A: It has one 10/100BaseT(X) port with a 4-pin M12 D-coded female connector, suited to vibration-prone installations.

Q: Which protocols and software does it support?
A: It supports Modbus TCP Server (Slave) and Moxa AOPC active tag communication, and works with MX-AOPC UA Server, the ioSearch utility and the MXIO library.

Q: What operating temperature range does it cover?
A: It is rated for -40 to 85°C, so it suits harsh rail and rolling-stock environments.

Q: What power supply does it require?
A: It accepts 12 to 48 VDC input power.

Q: How can it be mounted?
A: It can be mounted on a DIN-rail or on a wall.
