Moxa ioLogik E1510-M12-CT-T | ioLogik E1510-M12 Ethernet Remote I/O, 12 DI, Conformal Coating

Authorised Moxa Partner

SKU:ioLogik E1510-M12-CT-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa ioLogik E1510-M12-CT-T is a rugged Ethernet remote I/O module with 12 channel-to-channel isolated digital inputs and an M12 D-coded 10/100BaseT(X) port. It is the conformal coated, -40 to 85°C variant of the ioLogik E1500 Series, built for railway and rolling-stock deployments where vibration, moisture and wide temperature swings are routine.

Housed in a compact aluminium enclosure, it supports Modbus TCP Server (Slave), Moxa AOPC Active Tag and the MXIO library for Windows and Linux. Configuration is handled through the web console or the ioSearch utility, and the unit mounts on a DIN rail or on a wall with an optional kit. It operates from 12 to 48 VDC and is designed to meet EN 50121-4 and essential sections of EN 50155.

Features

- Designed to meet EN 50121-3-2, EN 50121-4 and essential sections of EN 50155 for railway applications
- Channel-to-channel isolation on every digital input channel
- Conformal coating for added protection in humid and harsh environments
- Wide -40 to 85°C operating temperature range
- Rugged, compact aluminium housing
- Active communication with the patented Active OPC Server
- User-definable Modbus/TCP Slave addressing
- Modbus TCP functions 1, 2, 3, 4, 5, 6, 15, 16 and 23 supported
- Simple mass deployment and configuration with the ioSearch utility
- MXIO library for Windows and Linux
- LED indicators for power, ready, expansion, LAN and each DI channel

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 12 x digital input channels, channel-to-channel isolated
- 1 x 10/100BaseT(X) port, M12 D-coded 4-pin female
- Magnetic isolation protection: 1.5 kV (built-in)
- Input voltage: 12 to 48 VDC
- Power consumption: 150 mA @ 24 VDC
- Conformal coating
- Operating temperature: -40 to 85°C (-40 to 185°F)
- Housing: aluminium
- Dimensions: 144 x 124 x 30 mm
- Weight: 825 g
- Mounting: DIN-rail, or wall with optional kit
- Wiring: I/O and power cable 16 to 26 AWG
- Ambient relative humidity: 5 to 95% (non-condensing)
- Standards: EN 50121-4, EN 50155, UL 508
- Shock: IEC 60068-2-27, vibration: IEC 60068-2-6
- Green product: RoHS, CRoHS, WEEE

FAQs

Q: What does the CT-T suffix mean on this ioLogik E1510-M12?
A: This model has conformal coating and an extended -40 to 85°C operating temperature range, which suits it to railway and other harsh environments.

Q: What type of Ethernet connector does it use?
A: It has one 10/100BaseT(X) port with an M12 D-coded 4-pin female connector, which is the standard for vibration-resistant rolling-stock networks.

Q: Which protocols and software tools does it support?
A: It supports Modbus TCP Server (Slave), Moxa AOPC Active Tag and the MXIO library for Windows and Linux. Configuration is via the web console or the ioSearch Windows utility.

Q: What power supply does it need?
A: It runs from 12 to 48 VDC and draws 150 mA at 24 VDC.

Q: How many inputs does it provide and are they isolated?
A: It provides 12 digital input channels, each with channel-to-channel isolation.

Q: How is the unit mounted?
A: It mounts on a DIN rail, or on a wall using the optional wall-mount kit.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
