Moxa AIG-302-T-AZU-LX | AIG-302 IIoT Gateway, Azure IoT Edge, Modbus, -40 to 85°C

Authorised Moxa Partner

SKU:AIG-302-T-AZU-LX

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa AIG-302-T-AZU-LX is a programmable IIoT edge gateway that connects Modbus RTU/ASCII/TCP devices to cloud platforms such as Azure and MQTT. This base model ships with Azure IoT Edge software on Moxa Industrial Linux and has no preinstalled LTE module, making it well suited to wide-temperature deployments rated from -40 to 85°C.

Built on a dual-core 1 GHz Armv7 Cortex-A7 processor with 2 GB DDR3L memory and 32 GB eMMC storage, it supports up to 3000 tags and offers two RS-232/422/485 serial ports plus a CAN port. A 12 to 48 VDC power input and an mPCIe slot for an optional LTE module let you adapt the gateway to different industrial sites.

Features

- Connects Modbus RTU/ASCII/TCP devices to Azure cloud and MQTT platforms
- Modbus TCP server mode supported
- Azure IoT Edge software included
- Moxa Industrial Linux for programmable edge applications
- Wide-temperature operation from -40 to 85°C
- mPCIe slot ready for an optional LTE module

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- CPU: Armv7 Cortex-A7 dual-core 1 GHz
- DRAM: 2 GB DDR3L
- Storage: 32 GB eMMC pre-installed
- OS: Moxa Industrial Linux (Debian 11, kernel 5.10.x)
- Tags supported: 3000
- Serial: 2 x RS-232/422/485 (DB9 male, 300 bps to 921.6 kbps)
- CAN: 1 x port (DB9 male, CAN 2.0A/2.0B, 10 to 1000 kbps, 2 kV isolation)
- Digital outputs: Euroblock terminal, 200 mA per channel, sink type
- Power input: 12 to 48 VDC
- Operating temperature: -40 to 85°C
- Expansion: mPCIe slot 1 for LTE module (none preinstalled), mPCIe slot 2 for Wi-Fi module (reserved)

FAQs

Q: Does the AIG-302-T-AZU-LX include an LTE module?
A: No. This is the base model with no preinstalled LTE module. It has an mPCIe slot for adding an LTE module.

Q: Which cloud platforms does this gateway connect to?
A: It connects Modbus RTU/ASCII/TCP devices to cloud platforms such as Azure and MQTT, and includes Azure IoT Edge software.

Q: What serial and fieldbus interfaces are available?
A: Two RS-232/422/485 serial ports on DB9 male connectors and one CAN port supporting CAN 2.0A/2.0B with 2 kV isolation.

Q: What operating system does it run?
A: Moxa Industrial Linux, based on Debian 11 with kernel 5.10.x, for developing programmable edge applications.

Q: What power input does the AIG-302-T-AZU-LX accept?
A: It accepts a 12 to 48 VDC power input.

Q: What operating temperature range does this model support?
A: This wide-temperature model operates from -40 to 85°C.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
